KALOS 35

Ultra high-definition 4K camera with 12.7MP 1/2 3" CMOS sensor and 3.5X (21.5 - 75mm) Optical Zoom. Record videos and take stills with more detail and sharpness even with low light.

Sensor: CMOS 1/2.3” 12.71 MP
Max. Resolution:
4152(H) x 3062(V)
Focal lenght: 3.85-13.4mm 3.5X optical zoom
F-number: F2.40(Wide) ~ F5.03 (Telephoto)
Field of View: 78(H)x63(V) deg wide, 26(H)x20(V) deg telephoto
Max. video resolution: 3840(H)x2160(V)
Framerate: 30 FPS
Power consumption: gimbal idle, recording encrypted video at max. resolution:
Video encoding: H.264/H.265
Snapshots: JPEG
Storage: MicroSD, up to 64GB
Minimum illumination: 0.5 Lux/F2.4
Operation enviroment: -20°C .. +40°C temperature 20% to 80%RH
Storage enviroment: -30°C .. +70°C 20%to 95%RH
